KIT DITEC DITCB24 24V CUBIC UNDERGROUND SWING GATES ML330
  • KIT DITEC DITCB24 24V CUBIC UNDERGROUND SWING GATES ML330

KIT DITEC DITCB24 24V CUBIC UNDERGROUND SWING GATES ML330

EAN.0615402508049

KIT DITEC DITCB24 24V CUBIC CANCELLO BATTERS INTERRATE ML330

€778.90
VAT included
Quantity
Last items in stock

  Security policies

Secure site in SSL certification for the security of your data

  Shipping policies

Shipping in 24/48 hours after payment

  Return policy

Maximum times for returns 14 days, the goods must return as shipped by us,

Description

KIT DITEC DITCB24 24V CUBIC INDUSTRY

24V DITEC underground engine kit cod. CUBIC6H

for two-way gate

Radio 433 MHz

Intensive use

(foundation case, leverisms and unblock NOT included)

Composition:

2 CUBIC6H LEVERISMI and SBLOCCHI INCLUDES

1 LCU40H control panel with built-in radio receiver

1 pair of LIN2 photocells

2 remote controls rolling code 2Ch (1xZEN2 + 1xZEN2W)

1 FL24 lamp complete with antenna and 5 m coaxial cable for antenna

+ warning panel E109B

Technical characteristics  CUBIC

Electromechanical actuator irreversible, for door up to 3.5 m

Magnetic end stroke management (optional)

Max capacity 600 kg x 2 m 250 kg x 3.5 m

Service class 3 - frequent

Intermittent S2 = 15 min S3 = 25%

Power supply 230 Vca / 50 Hz

Absorption 1.5A

Couple 340 Nm

Opening time 18 s/90

Maximum actuator opening 110° or 180°

Unlock for manual key opening

Operating temperature -20°C / +55°C (5°-35°C / +55°C with NIO activated)

Protection rating IP 67

Product Details
EAN.0615402508049
Attachments
Download
Technical manual

Ditec Cubic

Download (976.87KB)
