AJAX MOTIONCAM OUTDOOR WIRELESS OUTDOOR MOTION DETECTOR SENSOR WITH INFRARED CAMERA - AJAMCAMOUTD-W

MotionProtect Plus

Wireless motion detector. Notifies the owner to the first signs of an intrusion in the house or office. The detector is attached to a wall placed in front of doors and other places from which you can access the house or office. It ignores the movement of dogs and cats with a maximum weight of 20 kg and a maximum height of 50cm. The device accurately detects movement at high temperatures, even with 40 °С

Operation

The device detects human presence thanks to the infrared level, using a passive infrared sensor. The data received is digitally processed to avoid false alarms.

Description

The device automatically increases or decreases the sensitivity of the sensor to accurately detect the movement in cold and hot climates.

Installation and configuration

Ready to use: the battery is already installed, it is not necessary to disassemble the detector. Connect to the hub by mobile application with one click. Mount on the SmartBracket support in just a few minutes.

SENSOR ELEMENT PIR sensor

MOVEMENT RILEVATION DISTANCE Up to 12 m

VISION ANGLES OF MOVEMENT RILEVATOR (ORIZONTAL/VERTICAL) 88,5° / 80°

VELOCITY OF MOVING From 0.3 to 2 m/s

OPTION "DOMESTIC ANIMALS Yes, height up to 50 cm, weight up to 20 kg

For motion detectors react with animals and how to avoid it >

IT IS ALSO ANTI-SABOTAGE Yes

BANDA DI FREQUENZA 868.0 – 868.6 MHz or 868.7 – 869.2 MHz, according to the place of purchase

COMPATIBILITY Works with Ajax hubs, signal repeaters, ocBridge Plus, uartBridge

MASSIMA POTENCE OF USES RF Up to 20 mW

MODULATION OF THE SEGNAL RADIO GFSK

RAGGING THE SEGNAL RADIO Up to 1,700 m (open field)

ALIMENTATION 1 battery CR123A, 3 V

BATTERIA DURATION Up to 5 years

INSTALLATION Interior

FUNCTIONING TEMPERATURE From -10°С to +40°С

OUTSIDE Up to 75%

TOTAL DIMENSIONS 110 × 65 × 50 mm

PEOPLE 86 g

UT 10 years

CERTIFICATION Safety level 2, environmental class II in accordance with EN 50131-1, EN 50131-2-2, EN 50131-5-3
